Measuring Equipment

Zeiss Contura – CMM
Mahr Marsurf CD 280 – Contour Measurement
Mahr Surface – Portable Roughness Tester
Mahr Digital Height Gauge – 0–600 mm
Mitutoyo Vernier Calipers – 0–150 mm, 0–300 mm, 0–600 mm, 0–1000 mm
Mitutoyo Micrometers –
0–25 mm, 25–50 mm, 50–75 mm, 75–100 mm, 100–125 mm, 125–150 mm, 150–300 mm, 300–400 mm, 400–500 mm, 500–600 mm, 600–700 mm, 700–800 mm, 800–900 mm
Mitutoyo Bore Gauges –
18–35 mm, 35–60 mm, 50–150 mm, 150–250 mm, 250–400 mm, 400–600 mm, 600–800 mm
Mitutoyo Depth Gauges – 0–300 mm
Carbide Gauge Blocks...and many more

Physical properties

Dye Penetrant Test

Liquid Penetrant test is the Solvent Removable Process using colour contrast penetrant for detecting discontinuities that are open to the surface of weldments and materials of any shape or size. As per ASME Section VIII-DIV.1 Mandatory Appendix-8, 2017 Edition and ASME Section V, Article-6, 2017 Edition.

Magnetic Particle Testing

Magnetic Particle Test is used to detect surface and slightly subsurface flaws in most ferromagnetic materials such as iron, nickel, and cobalt, and some of their alloys. As per ASME Section VIIIDIV.1, ASME Section V Article-7 2019 Edition.

Radiographic Test

Radiographic examination of Carbon, Alloy, and SS welds using X-rays or gamma rays (Ir. 192/Co-60). As per ASME Section VIII Div 1 Edition 2019, UW51, UW-52, Mandatory Appendix 4; ASME Section V Article 2 Edition 2019; ASME Section IX Edition 2019, QW – 191.1; SE -999, Section V Edition 2019 and SNT – TC – 1A Edition 2006

Ultrasonic Test

By Manual contact ultrasonic examination of Butt welds, full penetration welds of Carbon Steel/Alloy Steel/stainless steel with a thickness range of 8 mm to 150 mm. For Weld Overlay/buttering on base material. As per ASME Section VIII Div. 1, 2019 Edition

Hydrotest Pump

Centrifugal Reciprocating Hydro Test Pump with pressure ranges – 5000 psi & 3500 psi (each).

Pressure- Time Chart Recorder

Circular chart Pressure-Time Chart Recorder with Display (Two Pen Stylus) for recording Hydrotest parameters in highly pressurized equipment.

PMI Measurement

Thermo Scientific USA manufactures a Positive Material Identification Gun (PMI) to ensure & identify the nominal composition of stainless steel/ alloy steel materials. This applies to the checking of material specified, including welds in accordance with the design requirements, using an instrument -Thermo Scientific, Model: NITON XL series.

Digital Ultrasonic Thickness Measurement

Portable Digital Ultrasonic Thickness Gauge with an Applicable range of 1.2 to 200mm.

DFT Meter

Dry Film Thickness Meter- Instrument used on the painted surface of ferrous and Non-Ferrous

Metal having a Range of 0 to 1300 Micron.

UV Black Light Testing

Specially used for oxygen-cleaning components for checking the presence of any foreign particles. Instrument Range- 220V,50 Hz, 1 Phase, UV Intensity – 5000µw / cm² nominal, Wavelength 365 nm, visible Light Intensity-Less than 10 Lux / 1 Foot candle.
